Image Processing for Orthopedic Surgery

Orthopedic surgeons can now benefit from the use of a mature set of computer vision and image processing tools for patient-specific measurement, navigation, surgical simulation, surface reconstruction, and implant design. These techniques are a breakthrough in the field of orthopedics, enabling to improve treatment, recovery times, surgery outcomes and the quality of life of patients.

Orthopedic Surgery: In-Op Navigation

This series of 5 articles by RSIP Vision about orthopedic navigation during surgery displays the state-of-the-art image processing techniques offering the surgeon a highly accurate and effective real time in-op view of the surgery environment. This procedure can be divided in several tasks: camera calibration of input imagessegmentation during orthopedic surgeriesregistration of CT and X-Ray; orientation and navigation during surgeryvalidation of accuracy in navigation systems. The outcome is a breakthrough advancement in orthopedic surgery performance, corroborated by rich academic literature supporting the method and by widespread use in the operation room. Read more...

Bones and Skeleton Segmentation

RSIP Vision suggests an automatic segmentation procedure based on iterative binarization of bone tissues density, as observed in Computed Tomography (CT), the most common 3D process used for bone imaging. This method is particularly fast, regardless of whether contrast was used in the CT scans. In fact, images taken with contrast generally display blood with an intensity which is similar to bone; our technique is able to overcome this challenge and to deliver a fast and satisfying bones segmentation and skeleton segmentation solution to our client. Read more...

Bone Segmentation in Orthopedic Surgery

Incorporation of new visualization technologies and planning methodologies shortens examination, planning and operation procedures in orthopedic surgery, while retaining the high standard of accuracy that are required in these common practices. Innovative algorithmic techniques, relying on image processing, computer vision and machine learning are increasingly utilized and have gained approval by regulatory bodies such as the FDA, leading to what is better known as Computer Assisted Orthopedic Surgery (CAOS) procedures. This requires accurate bone segmentation, better performed using the method which we recommend. Read more...

Point and Surface Registration

Point and surface registration enable computer vision and image processing to improve surgical orthopedy practices and affect surgery outcome recovery. Bringing point and surface registration in the field of orthopedics, computer vision and image processing hold the potential to improve surgical practices and affect surgery outcome to favor the benefit of patients and fast recovery. Measurement accuracy (within less than 1 mm) is a strict constraint to computer-vision-based algorithms. Read more...

Detection of Bone Cancer

Metastatic bone malignancies arise following prostate cancer (80% of cases, with 3% five-year survival rate), breast cancer (with no cure) or lung cancers (with 11% two-year survival rate). Bone metastases affect more than 400,000 people annually in the United States with frequent occurrences among patients undergoing irradiation and secondary effect to other treatments. Detection of skeletal metastases has a major impact on devising treatment strategies and prognosis. The solution offered by RSIP Vision produces 3D surfaces of bones and other skeletal-related structures to detect and quantify primary and metastatic bone cancer. Read more...

Anatomical Reconstruction with Sparse Set of Points

Advance navigation techniques in orthopedic surgery allow to construct 3D models of patients’ anatomical parts by matching a surface to an acquired set of data points. As an alternative to costly imaging procedures, ultrasound or fluoroscopic scan can be performed with much reduced costs and hazards. A set of surface points marked by the technician or physician forms then an initial sparse set for anatomical surface reconstruction. Here we show how RSIP Vision's engineers overcome the challenge of using a sparse set of points to accurately reconstruct a complex 3d surface. Read More

3D Reconstruction for Bone Alignment

Advances in vision-based medical imaging have completely transformed orthopedic surgery planning and operation procedures. A practical example is a high-impact femur fracture, resulting in a noticeable separation into two segments of the femur. Surgery in such cases requires initial alignment of the proximal and distal parts of the broken bone, followed by insertion and securing of a nail. In RSIP Vision's solution, image features are matched to a pre-designed flexible geometrical model of the bone. Read more...
